TV Encoder Streamer

Up to 24 HDMI MPEG4 AVC/H.264 HD Encoder engines in 1 box
The BLANKOM 8600 TV to IP Encoder-Streamer is a professional HD audio & video encoding and multiplexing device.
Input: 8 ... 24 HDMI compatible Video input interfaces, supporting MPEG-4 Video encoding and MPEG 1 Layer 2 audio encoding. This very compact Encoder simultaneously encodes up to 8 ... 24 HDMI compatible HD Audio & Video channels to IP output as a multiplexed 1 MPTS and 8 ... 24 SPTS IP SPTS output streams as UDP Multicast. Every encoded Video-picture can be added with Text, Graphic or QR-code overlays. High integrated and cost effective design fits perfect into widely use cases in varieties of digital distribution systems such as cable TV digital head-end, satellite digital TV broadcasting etc.

• Available as 08 - 12 - 16 or 24 Input versions
• Full HD support in h.264 max. 1920×1080p60 to min. 720x480i60
• GOP Structure IP…P (P Frame adjustment, without B Frame )
• Modular: N x 8 SPTS (8/12/16/24 SPTS) IP and 1,2,3,4 MPTS output over UDP/RTP/RTPS*,
• Encoding Rate Control CBR/VBR, PCR adjusting and inserting
• 1 ASI output (optional) (Copy of the MPTS)
• PSI/SI rebuilding and editing & “Null PKT Filter” function, PID filtering and re-mapping

Up to 24 HDMI encoder engines with enhanced features
HDMI TV Encoder IP Streamer
MPEG4 AVC/H.264 HD IP Encoder is a professional HD audio & video encoding and multiplexing device. Input: 8 ... 24 HDMI compatible Video input interfaces, supporting MPEG-4 Video encoding and MPEG 1 Layer 2 audio encoding. This very compact Encoder simultaneously encodes up to 8 ... 24 HDMI compatible HD Audio & Video channels to IP output as a multiplexed 1 MPTS and 8 ... 24 SPTS IP SPTS output streams as UDP/RTP Multicast. Every encoded Video-picture can be added with Text, Graphic or QR-code overlays. High integrated and cost effective design fits perfect into widely use cases in varieties of digital distribution systems such as cable TV digital head-end, satellite digital TV broadcasting etc.

• h.264 Video-Encoder with 8/12/16/24 Inputs
• Encoding with highest compression format with B frames (IBBP)
• Audio Codecs: MPEG1L2, AAC, AC3pass
• 8 HDMI* input, 8 SPTS IPTV and 1 MPTS output (EMU 8508)
• 12 HDMI* input, 12 SPTS IPTV and 1 MPTS output (EMU 8512)
• 16 HDMI* input, 16 SPTS IPTV and 2 MPTS output (EMU 8516)
• 24 HDMI* input, 24 SPTS IPTV and 3 MPTS output (EMU 8524)
• Optional: 1/2/3 ASI output (Copy of the MPTS)
• On-Screen Graphics, Scrolling Text, QR Code insertion
• Multiplexing: PCR adjusting/ PSI/SI rebuilding and editing / PID Filtering and Remapping
• “Null PKT Filter” function for multiplexed MPTS out
• Web-based remote configuration management

04, 08 or 12 HD-SDI sources to HEVC or h.264
BLANKOM HD-SDI HEVC/h.264 encoder - streamer
MPEG4* AVC/H.264 and HEVC/h.265 HD IP Encoder is a professional HD audio & video encoding and multiplexing device. Input: 4, 2x4 or 3x4 HD-SDI Video input interfaces, supporting HEVC and MPEG-4* Video encoding and MPEG 1L2, AAC and AC3 passing audio encodings. This very compact Encoder simultaneously encodes up to 4, 8 or 12 HD-SDI compatible HD Audio & Video channels to IP out as a multiplexed 1..3 MPTS and 4, 8 or 12 SPTS IP streams as UDP/RTP/RTSP Multi-/Unicast per Module. Every encoded Video-picture can be added with Text, Graphic or QR-code overlays: As optional feature available. High integrated and cost effective design fits perfect into widely use cases in varieties of digital distribution systems such as cable TV digital head-end, satellite digital TV broadcasting etc. * Dep. On common Resolutions

• HEVC/h.264 Video-Encoder with 4/8/12 Inputs
• Encoding with highest compression format—B frame (IBBP)
• Audio Codecs: MPEG1 Layer2, AAC, AC3pass
• 4 SDI input, 8 SPTS IPTV and 1 MPTS output (EMU 8204)
• 8 SDI input, 8 SPTS IPTV and 2 MPTS output (EMU 8208)
• 12 SDI input, 12 SPTS IPTV and 3 MPTS output (EMU 8212)
• Nx MPTS IP output over UDP, RTP/RTSP to monitor or forwarding
• On-Screen Graphics, Scrolling Text, QR Code insertion optional
• PCR adjusting/ PSI/SI rebuilding and editing / PID Filtering and Remapping
• “Null PKT Filter” function for multiplexed MPTS out

HD-SDI and HDMI-4K Encoder family
4, 8 or 12× HD-SDI or HDMI 1.4/2.0 inputs

• 1x Network Management Service-(NMS-Web-Interface) and 1 or more GbEthernet data-streaming -port(s)
• ASI output as Copy of an MPTS (Multiplexed Transport Stream) (optional)
• Audio-Encoding: MPEG-1 Layer 2, LC-AAC, HE-AAC and AC3 Pass through*
• Accurate PCR adjusting and inserting
• Streaming Protocol's supported: Unicast RTSP and Multicast UDP/RTP
• PID filtering and re-mapping
• PSI/SI rebuilding and editing & “Null PKT Filter” function
• Optional On-Screen Graphics, Scrolling Text, QR Code insertion*
• *=Depending on Model and selected features when ordering

• SDI (EMU-92xx) supports only up to Full HD in HEVC h.264 max. 1920×1080p60
• 4/8/12×HD-SDI or HDMI 1.4/2.0 inputs
• HEVC encoder parts (4 per module) supporting max. 4x 1080p60 while h.264 encoding is limited to 2ch per module
• HDMI V2-Input support: max. 3840×2160p30 resolution: HEVC 2 channel/module, h.264 = 1 channel/module
• Lower than FullHD: 1280×720p60 => Encoding 4 channel per module for h.264 and h.265
• GOP Structure IBBP, IPPP
• Video correction: De-interlacing, Noise Reduction, Sharpening
• Audio-Encoding: MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2, AC3 Passthrough

BLANKOM Full HD MPEG2 and h.264 AVC broadcast Versions
1-Input MPE-4001, 4 Inputs: MPE-4400 = MPE-4400S or H, S= SDI H=HDMI Inputs
The BLANKOM MPE-4001 Single Video Encoder has both inputs HD-SDI and HDMI with full HD MPEG2 and h.264 AVC codecs by D7 Magnum Chip support (EoL).
MPE-4400:
MPEG-2/H.264 SD/HD 4x Encoder is a broadcasting audio & video encoding device with powerful functionality. Equipped with 2 Modules 2x 2x HD-SDI or 2x 2x HDMI or mix of. Multiple audio and video encoding formats are available to meet your flexible and various requirements. AC3 (2.0) can be processed as well. The encoded program will finally output in a DVB conform TS through 2 parallel ASI and 1 IP port: MPTS & 4 SPTS.

• The MPE-4001 is equipped with 1 Encoder-Engine: Up to Full HD in MPEG2 (p+i) and h.264 (p+1) max. 1920×1080p60
• Designed for Low Latency operation(150ms)
• 2x independent Gigabit Ethernet Ports for IP IN/OUT, 1x ASI out as TS-Multiplex
• External mixed input or 2 Stereo-Audio channels (4 Mono) within HD-SDI-Eingang
• MPEG1 Layer II, HE-AAC (v1 & v2), LC-AAC and DD AC3 2.0 Audiocoding and -adjustment
• VBR/CBR-Encoding rates selectable, cascadable through ASI - IN and Out to the next MPE-4001 or multiplexer
• 2x ASI-Inputs and IP as MPTS and SPTS, UDP/RTP
• Audio-Encoding: MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2, AC3 Passthrough
• Enhanced version (MPE-4000) with MPEG2 4:2:2 and Magnum D7 Chipset - available upon request

• The MPE-4400 uses 2 dual encoder modules: Each 2x Full HD in MPEG2 (p+i) and h.264 (p) max. 1920×1080p60
• Flexible available as MPE-4200 (S/H) with only 1 dual module installed
• S and H Modules can be mixed in one unit = 2x HD-SDI and 2x HD-HDMI Inputs
• Low Latency support: Normal, mode 1, mode 2
• Up to 4 Stereo Audio Channels (8 Mono) supported per HD-SDI Input
• MPEG1 Layer II, HE-AAC (v1 & v2), LC-AAC and DD AC3 2.0 audio encoding and adjustment: Support Volume normalization for AC3
• VBR/CBR encoding rate control mode
• Dual parallel ASI output and IP as MPTS and 4 SPTS, UDP/RTP
• Audio-Encoding: MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2, AC3 Passthrough

Modular IP to HD-SDI Decoder
IGS-2000/4000/6000 The Eoncoder - Streamer counterpart: A broadcast grade IP Input to HD-SDI Output Decoder
The BLANKOM IGS x000 (Integrated SDI- Decoder) is a designed broadcast grade companion unit for MPE-4400 Encoder (H= HDMI, S=SDI versions). After de-multiplexing and decoded, the content output can be re-passed to ASI, IP as Multiplex. Its outputs support professional HD/SD-SDI, 2x Stereo Audio embedded for professional needs. Easy operation by using the inbuilt comfortable Web-Interface. Available with 2, 4 or 6 SDI ports.

• The IGS-2000 comes with a modular - so scalable design with 2, 4 or 6 HD-SDI Outputs
• 2x HD/SD-SDI decoding output with 2 Stereo Audio embedded in each port
• DECODING 480i,480p,576i,576p,720p@50/59.94/60, 1080i@50/59.94/60
• 2x IP input and 1 IP output
• 2x Bi-directional ASI ports with input or output mode selectable
• MPEG-2 and MPEG-4 AVC/H.264 Video Decoding
• MPEG1 Layer2, LC-AAC, HE-AAC, AC3 (2.0/5.1), AC3 Pass-through for Audio
• Internal Re-multiplexer
• CC/Subtitle support
